Fx-703: 1024B mini pearl

DMX512 channel number: 1024

Computer lights: 96

Scanner re-matching address code: supported

Lamp horizontal and vertical exchange: supported

Lamp channel reverse output: supported

Lamp channel sliding mode switch: supported

Max control channels for each scanner: 40 main channels + 40 fine-tuning channels

Fixture Library: Pearl R20 Fixture Library supported

Saved scenes: 60

Simultaneously running scenes: 10

Total steps in a multi-step scenario: 600

Scene time control: fade in, fade out, LTP slide

Graphics per scene: 5

Fader for scene start and dimming: supported

Interlocking scene: supported

Point control scene: supported

Graphics generator: Dimmer, P/T, RGB, CMY, Colour, Gobo, Iris, Focus graphics

Simultaneously running graphics: 5

Master fader: global, repeat, lamps

Blackout immediately: supported

Turntable to adjust channel value: supported

Fader to adjust channel value: supported

Push rod dimming: supported

U disk read: FAT32 format supported

MIDI music synchronization: supported

Create/Edit Light Library: supported

Program backup and recovery: supported
